Zipwake 2022013 | Series E PRO KB1000-E PRO Dynamic Trim Control Kit Box with Two 1000 mm (39.4 in) Interceptors
Zipwake

Zipwake 2022013 | Series E PRO KB1000-E PRO Dynamic Trim Control Kit Box with Two 1000 mm (39.4 in) Interceptors

SKU
Sold out
$14,546.40 - $14,546.40
$14,546.40
$14,546.40 - $14,546.40
$14,546.40
Availability Out of stock Lead Time Typically Ships within 1 Week In Store - Online Only - This item is stored in an external warehouse. Online orders will be shipped direct to the shipping address or available for in-store pickup typically within 1-3 days.
Unavailable for Same-Day Pickup or Local Delivery

30-Day Return Policy | See Details.

Need Help From Our Sales Team?

Available during our normal business hours:

The Zipwake KB1000-E PRO is a complete Series E PRO kit box built around two 1000 mm (39.4 in) straight interceptors. It packages the matched control, distribution and interceptor components specified for this exact kit.

This standard configuration includes the dedicated Zipwake control panel for direct helm operation.

Product Information

Brand Zipwake
Series Series E PRO
Model KB1000-E PRO
Manufacturer Part Number 2022013
Product Type Dynamic Trim Control Kit Box
Configuration Straight
Interceptor Size 1000 mm (39.4 in)

Key Features

  • Factory-defined Series E PRO kit configuration
  • Matched pair of straight interceptors
  • Control or integration hardware matched to the kit model
  • Exact component quantities confirmed in the current Zipwake specification

Specifications

Kit Configuration Straight
Interceptor Size 1000 mm (39.4 in)
Packaged Dimensions 1130 x 192 x 458 mm (44.5 x 7.6 x 18 in)
Packaged Weight 32.8 kg (72.3 lbs)
System Supply Voltage 12–32 V DC
Interceptor Servo Voltage 36 V DC
Maximum Boat Speed 60 knots
Blade Stroke 60 mm (2.4 in)
Blade Rate 200 mm/s (7.9 in/s)

Included

  • 1 × CP PRO control panel with 7 m (23 ft) standard cable
  • 1 × EC5-M12 extension cable, 5 m (16 ft)
  • 1 × DU PRO distribution unit with 4 m (13 ft) power cable
  • 2 × IT1000-E PRO interceptors, each with 3 m (10 ft) cable and cable cover components

Compatibility

Designed as the exact KB1000-E PRO configuration for Zipwake Series E PRO. Components from other series or non-PRO/PRO generations must not be mixed.

Installation Notes

  • Verify system sizing, interceptor placement and hull suitability before installation.
  • Use the exact Zipwake installation instructions and drill templates for the included interceptor models.
  • Connect power protection, networking and cable extensions only as specified for this series.

Important Information

This is a complete kit box with the exact components listed above. Do not replace the verified interceptor size or configuration with another model.
