Muir M2200L24-5/16H | Storm 2200, 24V, Vert. Rope/Chain Windlass f/ 5/16"HT/BBB
Imtra

Muir M2200L24-5/16H | Storm 2200, 24V, Vert. Rope/Chain Windlass f/ 5/16"HT/BBB

SKU
Save 3% Save 3%
$3,800.00
$3,800.00 - $3,800.00
$3,800.00
$3,702.15
$3,702.15 - $3,702.15
$3,702.15
Availability In Stock In Store - Online Only 2 This item is stored in an external warehouse. Online orders will be shipped direct to the shipping address or available for in-store pickup typically within 1-3 days.
Unavailable for Same-Day Pickup or Local Delivery
$ Oversized | Not Eligible For Free Shipping

30-Day Return Policy | See Details.

Need Help From Our Sales Team?

Available during our normal business hours:

Muir Storm 2200, Vertical Powered Rope/Chain Windlass, Low Profile, 24V, 1500W, 316 Stainless Steel

Standard Equipment:

Two (2) Covered Footswitches

Watertight Dual Direction Solenoid Box

Rope Chain Management System

Clutch Handle

Replaces old item number MSS2200R24E

Features

  • The Self-Aligning QuickFit Gearbox Coupler allows the gearbox and motor to be installed directly onto the shaft in any radial position and alleviates installation problems due to uneven deck thickness. This is helpful when installing a windlass onto a deck with any camber to the deck surface. QuickFit connection simplifies installation.

Specifications

Brand Muir
Manufacturer Part Number M2200L24-5/16H
Motor Wattage 1500W
Version Low-Profile
Warranty 5 years
Vessel Length 38-48 ft (12-15m)
Standard Equipment RCMS, 2 x Footswitches, Solenoid Control Box, Handle
Max Load 2420 lb (1100 kg)
Approximate Boat Size 40 - 49 ft.
Work Load 550 lb (250 kg)
Amperes @ Working Load 70
Amps Work Load 75
Max Line Speed 98 ft/min (30 m/min)

Brand: Imtra

WARNING: This product MAY expose you to chemicals, which are known to the State of California to cause cancer, birth defects and/or other reproductive harm. For more information go to www.p65warnings.ca.gov

Weight:
Dimensions: x x
Barcode:

Backorder Policy: Occasionally, due to demand or supplier delays, some items may be temporarily out of stock or non-stock items. To ensure you can still get the products you need, you can order items even when they're out of stock. Our sales team will update you with the shipping lead time. Once back in stock, we promptly ship your item, and if your order includes both in-stock and backordered items, we may split the shipment. You can cancel your backorder before shipment, and request a refund to original payment method. For any inquiries, contact us at sales@freeportmarine.com.

No documentation available for this item.
