Blue Sea 7042 187-Series Circuit Breaker - Panel Mount 80A

Blue Sea 7042 187-Series Circuit Breaker - Panel Mount 80A

SKU BLU7042
Brand Blue Sea
Availability :
0 In Stock, Available for Order
$91.99 - $91.99
$91.99
$91.99 - $91.99
$91.99

Simple Returns & Same Day Shipping*

30-Day Return Policy. In-stock items ship same day if ordered by 2:00 PM EST. Place overnight & 2-day orders by 1:00 PM EST. Orders after these times ship the next business day. *Shipping Policy

Need It Fast?

We offer Local Delivery & Expedited Shipping through our trusted logistics partners, as well as FREE In-Store Pick Up.

Need Help From Our Sales Team?

Available during our normal business hours:

7042 187-Series Circuit Breaker - Panel Mount 80A

Features:

  • Combines switching and circuit protection into a single device*
  • Precise, single-lever operation
  • "Trip Free" design cannot be held "ON" during fault current condition
  • Waterproof
  • Recessed mounting holes for clean appearance
  • Ample Clearance around terminal studs accepts heavy gauge wire lugs
  • Robust 5/16 M8 terminals provide high torque connections
  • Large lever with vertical/horizontal orientation provides indication of trip status
  • Ignition-protected - Safe for installation aboard gasoline powered boats

Specifications:

  • Amperage: 80A
  • Maximum Voltage: 48V DC
  • Mounting: Panel Mount
  • Circuit Breaker Type: Thermally responsive Bi-metal blade
  • Terminal Stud Torque: 75 in-lb (8.47 Nm)
  • Interrupt Capacity: 5000A @ 14VDC, 3000A @ 28VDC, 1500A @ 48VDC
  • Minimum Operating Temperature: -40 ° C
  • Maximum Operating Temperature: 85 ° C
  • Case Material: Thermoset Polyester
  • Circuit Breaker Class: Type III - switchable/manual reset - trip-free
  • Mounting Hole: Accept #10 (M5) Screw
  • Terminal Stud Size: 5/16" - 18
  • Weight: 0.5lb (0.23 kg)
  • Weight: 0.50lb (0.23 kg)

* Do not use as a switch where high inrush currents are expected.
