Roca W10 Heavy Duty Marine Wiper Motor 24V with 1.5 Inch Shaft Two Speed Self Parking
par Imtra

Roca W10 Heavy Duty Marine Wiper Motor 24V with 1.5 Inch Shaft Two Speed Self Parking

UGC
Épuisé
$245.73
$245.73 - $245.73
$245.73
$157.05
$157.05 - $157.05
$157.05
Disponibilité Rupture de stock In Store - Online Only - This item is stored in an external warehouse. Online orders will be shipped direct to the shipping address or available for in-store pickup typically within 1-3 days.
Unavailable for Same-Day Pickup or Local Delivery

30-Day Return Policy | See Details.

Need Help From Our Sales Team?

Available during our normal business hours:

The Roca W10 Heavy Duty Wiper Motor is a 24V unit with a 1-1/2 inch shaft, ideal for protected marine installations with shallow bulkhead depth. It is engineered to drive long wiper arms and blades even in heavy weather conditions. The motor features a solid-brass, nickel-plated knurled drivenut and bearing, while the drive shaft, mounting bracket, and fasteners are all made from stainless steel for corrosion resistance. Proprietary motor magnets contribute to quieter performance compared to similar models on the market.

  • Two speed operation: Low at 35 sweeps per minute, High at 55 sweeps per minute
  • Self parking feature, adjustable for right or left side
  • Delivers 10Nm of torque
  • Supports pendulum arms up to 26 inches and pantograph arms up to 24 inches with blades up to 22 inches
  • CE approved and EMC protected
  • Includes a 3 year manufacturer warranty
Name Description
Manufacturer Part No RC525992
Voltage 24V
Finish White Powder Coated
Shaft Length 1-1/2 in.
Standard Sweep Angles 45, 60, 80 and 110 degrees
Bulkhead Thickness 10mm to 16mm (3/8 in. to 5/8 in.)
Sweep Angles with Optional Disc 70, 80, 90 and 100 degrees
Optional Sweep Disc RCSWDISCSP
24 inch Wiper Arms All Standard and Heavy Duty W10 and W12 Arms
22 inch Wiper Blades EX2170CN to EX2175 (requires EX2108K arm) and RC520911 to RC520922 (compatible with all W10 and W12 arms)
Optional Motor Cover RC528614
